关键词: 智能牧场管理, 虚拟电子围栏, 多模态数据融合, 在栏判断算法

Abstract:

Physical fences such as barbed wire laid in traditional wild pastures are not conducive to livestock transhumance, wildlife migration and grassland ecological connectivity, and the existing virtual electronic fences are mostly localized with the help of electronic maps and contact smart collars worn by individual livestock, which result in high animal stress reaction, easy to fall off the equipment and high data maintenance cost. By integrating the binocular stereo vision, GPS positioning and IMU sensor data collected by the grazing robot, we construct a multimodal data fusion-driven livestock location sensing and in-fence judgment model. Taking the cattle under the natural grazing state in the field pasture as the research object, the virtual electronic fence boundary data of the pasture is constructed based on the Gaode map API; the YOLOv8s model is used to extract the individual target information of the cattle based on the binocular stereo image, and the depth information of the binocular stereo image is used to parse the spatial distance information between the recognized cattle target and the grazing robot, which is then fused with the GPS absolute positioning data and IMU positional data of the grazing robot. Then, fusing the GPS absolute positioning data of the grazing robot and the IMU position data, the Extended Kalman Filter algorithm is used to map the geospatial coordinates of the spatial position of the cows, and the latitude and longitude coordinates of the positioning of the cows under the field of view of the machine are solved; the vertex fine-tuning strategy and buffer warning mechanism are introduced, and the improved ray method (Pnpoly algorithm) is used to get the judgment data of the cows at the fence of the virtual electronic fence. We continuously collect 200 cattle movement trajectory data, and experimentally verify the data fusion, parsing and acquisition in the virtual electronic fence scenarios of convex polygon, concave polygon and irregular boundary, and the accuracy rate of in-fence judgment is 97.8%, which is 4.3% higher than that of the traditional algorithm. The results show that the multimodal data-driven method based on the fusion of machine vision and sensors has strong adaptability and engineering application value in the field ranch environment, and can provide non-contact, high-precision, continuous and stable virtual electronic fence spatial management data for livestock management.

Key words: smart pasture management, virtual electronic fence, multimodal data fusion, in-fence judgment algorithm
